InfiNet Wireless R5000 Technical User Manual
Copyright © 2004-2006 by InfiNet Wireless Limited.
13
Step 3. To disassemble the connector
detach its bottom part by turning it
clockwise as shown
Step 4. Disassembled connector is
shown on the picture
Step 5. Insert the cable into the
bottom part of the connector
