InfiNet Wireless R5000 Technical User Manual
Copyright © 2004-2006 by InfiNet Wireless Limited.
14
Step 6. Solder the top side of the
connector according to the soldering
scheme. Unscrew the top side of the
connector from the unit
Step 7. Using outdoor unit as a holder
assemble the connector
