InfiNet Wireless R5000 Technical User Manual
Copyright © 2004-2006 by InfiNet Wireless Limited.
16
Step 5. Screw Part 2 on Part 4. This
fixes the “RJ-45” connector on the
cable. Check that the connector is
properly fixed on the cable.
Step 6. Assemble the connector to the
unit.
Step 7. Fix the connector by screwing
Part 3.
Now the connector is hermetically
attached to the unit.
