28
Basic Picture menu
To adjust the following settings, highlight the setting, press Select, use the
up and down arrows to adjust the values, then press Select to confirm the
changes.
Brightness: changes the intensity of the image.
Contrast: controls the degree of difference between the lightest and darkest
parts of the picture and changes the amount of black and white in the
image.
Sharpness: (video sources only) changes the clarity of the edges of a video
image. Select a sharpness setting.
Color: adjusts a video image from black and white to fully saturated color.
The color setting applies to video sources only.
Tint: adjusts the red-green color balance in the image of NTSC video
images. The tint setting applies to NTSC video sources only.
Aspect Ratio: Aspect ratio is the ratio of the image width to image height.
TV screens are usually 4:3. HDTV and most DVDs are 16:9. The default is
4:3.
Select Auto to have the projector choose the ratio. Choose Native to see the
unmodified input with no resizing by the projector.
Select 16:9 to watch enhanced widescreen DVDs.
For more information regarding Aspect Ratio, see page 12.
Apply Preset...: Presets are provided that optimize the projector for dis-
playing computer presentations and video images under certain conditions.
There are also user-definable presets. To set a preset, adjust the image, select
Save User in the Presets menu. You can recall these settings in the future by
selecting the User preset.
Keystone: adjusts the image vertically and makes a squarer image. You can
also adjust keystone from the keypad.
Basic Picture
menu
Aspect ratio
Auto
Native
4:3
16:9
Letterbox
Panorama
Basic Picture
Contrast
Sharpness
Color
Tint
Aspect Ratio
Apply Preset
50
50
50
50
Auto
increasing keystone
decreasing keystone

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the InFocus IN2102 and is the answer not in the manual?

InFocus IN2102 Specifications

General IconGeneral
Matrix size0.55 \
Projection distance10 m
Vertical scan range50 - 85 Hz
Horizontal scan range31 - 79 kHz
Projection technologyDLP
Contrast ratio (typical)2000:1
Projector native resolutionSVGA (800x600)
Keystone correction, vertical-20 - 20 °
Aspect ratio4:3, 5:4, 16:9
RS-232 ports1
Dimensions (WxDxH)297.2 x 228.6 x 99.1 mm
Power requirements100 - 240, 50 - 60 Hz
Connectivity technologyWired
Lamp power200 W
Light source typeLamp
Service life of light source2500 h
Service life of light source (economic mode)3000 h
Analog signal format systemNTSC, PAL, SECAM
RMS rated power2 W
Microphone inYes
Serial interface typeRS-232
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Component video (YPbPr/YCbCr) in2
Noise level35 dB
CertificationUL, c-UL, FCC-A, CE, GOST, TUV GS, CCC, IRAM, NOM, C-Tick, MIC, eK, PSB
Power consumption (typical)250 W
Operating temperature (T-T)5 - 31.11 °C
Weight and Dimensions IconWeight and Dimensions
Weight3130 g
Package weight5260 g
