Setting up the Projector
Connecting a Video Device
1 If your video player uses a round, one-prong composite video
connector, you’ll need only the audio cable, audio adapter,
and composite video cable that shipped with the projector.
NOTE: HDTV sources are
connected to the projector using
the computer cable. See the
previous pages for details.
•
If your video player uses a round, four-prong S-video con-
nector, you’ll need an S-video cable in addition to the audio
cable and audio adapter. The S-video cable is sold sepa-
rately. (See “Optional Accessories” on page 56.)
2 Plug the composite video cable’s yellow connector into the
“video-out” connector on your video player (Figure 9). This
connector may be labeled “To Monitor.”
•
If you’re using an S-video cable, connect it to the “S-video
out” connector on the video player (Figure 10).
3 Plug the other yellow connector into the composite video con-
nector
on the projector.
•
If you’re using S-video, plug the other end of the cable into
the “S-video” connector
on the projector (Figure 10).
F
IGURE
9
Connecting the projector to a video player using the standard video cable (with com-
posite video connector) and the audio cable and adapter
composite video
audio cable
audio
adapter
cable
