13
The module provides the following audio/video inputs:
The module also provides wired remote input (used with an
optional remote), monitor out (used to display images on your
desktop computer’s monitor as well as on the projection screen),
and RS-232 input (to control the projector from an LCD control
panel).
NOTE: Specific RS-232 com-
mands can be found in the Service
and Support section of our website
at www.infocus.com.
Source Video Audio
Computer
2 VESA
VESA Single-ended ana-
log RGB (HD-15)
mini jack
Computer
1 M1-DA
M1-DA Single-ended
analog or digital
mini jack
Compo-
nent Video
Base-band component
video (RCA)
Left and right line-level
(2 RCAs)
Composite
Video
Base-band composite
video (RCA)
Left and right line-level
(2 RCAs)
S-Video S-video Y/C (4-pin circu-
lar)
Left and right line-level
(2 RCAs)
