2. Installation and Operation
NOTE: Before installation, please inspect the unit. Make sure that nothing inside the package is damaged.
Please keep the original package in a safe place for future use.
NOTE : E4 Evolution II TT UPS range don’t have built-in batteries and are connected to an external battery
cabinet :
Model
Version
E4 Evolution II 100k TT S HV
Long-run model
High Voltage
E4 Evolution II 120k TT S HV
E4 Evolution II 160k TT S HV
E4 Evolution II 200k TT S HV
High Voltage (HV) means rated voltage 380 / 400 / 415 VAC
2-1. Unpacking and Inspection
6. Use a forklift to move the product to
installed area. Refer to Figure 2-1.
Please make sure the bearing
capacity of forklift is sufficient.
7. Follow the unpacking order as above to remove the carton
( and ) and foams ( ).
place the plate ( ) in front of the pallet
