3. Control Panel & LCD Operations
3-1. Introduction
This control panel and display screen are located at the front panel of the UPS. This interface allows to
monitor all measured parameters, the UPS status, the battery status and alarms. The control interface is
divided into four sections: (1) LCD display, (2) LED indications, (3) Power Button, (4) Audible Alarm, as
shown in Figure 3-1.
Figure 3-1 Control Panel
(5) LCD display: Graphic display and all measured parameters.
(6) LED indications. Refer to Table 3-1.
(7) Power Button. Refer to Table 3-2.
(8) Audible Alarm. Refer to Table 3-3.
Table 3-1: LED Indications
Input source is abnormal.
Input source is abnormal.
There is power output for the load.
There is no power output for the load.
Battery converter is normal and battery is charging.
Table 3-2: Power Button
Turn on UPS or Turn off UPS. (hold 2-Sec)
To Next Page
