(12) UPS status: The meanings of each icon are listed as below.
Icon
UPS status
UPS operates in Standby
mode or Shutdown Mode.
UPS operates in Line mode or
Converter Mode.
UPS operates in Bypass mode
or ECO Mode.
UPS operates in Battery mode
or Battery Test Mode.
UPS operates in Fault mode.
3-2-3. Control Screen
Touch icon to enter into the submenu as shown below.
Control Menu Tree
