6.3.3 ‘‘MEASURES’’ level (screen menu 2.0).
Fig.25. Screen 2.0 “Measures” and its submenus.
()
()
screen 2.24 screen 2.23screen 2.22
()
()
()
()
OUTPUT APPARENT
POW L1=9.4KVA
OUTPUT APPARENT
POW L2=9.1KVA
OUTPUT APPARENT
POW L3=8.6KVA
screen 2.3screen 2.2
()
()
()
()
()
()
screen 2.1
I.VOLTAGE V12=398.3
V23=397.7 V31=400.2
I.VOLTAGE V1N=227.4
OUT. VOLT V1N=230.1
V2N=229.8 V3N=230.0
INV. VOLT V1N=230.0
V2N=230.7 3N=229.9
screen 2.21 screen 2.20screen 2.19
()
()
()
()
INPUT ACTIVE POWER
L3=9.4KW
INPUT TOTAL POWER
28.8KVA 28.7KW
INPUT P.F. L1=0.99
L2=1.00 L3=1.00
screen 2.27 screen 2.26screen 2.25
()
()
()
()
OUTPUT ACTIVE
POWER L1=8.2KW
OUTPUT ACTIVE
POWER L2=8.8KW
OUTPUT ACTIVE
POWER L3=8.1KW
screen 2.30 screen 2.29Screen2.28
()
()
()
()
OUTPUT TOTAL POWER
27.1KVA 25.1KW
OUT. P.F. L1=0.87
L2=0.96 L3=0.94
OUTPUT LD: L1=47.0%
L2=45.5% L3=43.0%
screen 2.33 screen 2.32screen 2.31
()
()
()
()
TOTAL LOAD
IN:53.8% OUT:52.3%
To Next Page
