8 APPENDICES
8.1 GENERAL TECHNICAL SPECIFICATIONS.
Nominal power (kVA) 10 15 20 30 40 60 80
INPUT
Nominal voltage Three phase 3x380 V, 3x400 V or 3x415 V (4 wires: 3 phases + N).
Input voltage margin + 15% / –20%.
Frequency 50 / 60 Hz ±5 %.
Input current total harmonic
distortion
100 % load: THDi < 1.5 %.
50 % load: THDi < 2.5 %.
10 % load: THDi < 6.0 %.
100 % load: THDi < 1.0 %.
50 % load: THDi < 2.0 %.
10 % load: THDi < 5.0 %.
Current limit High overload: PFC Limit (discharging batteries).
Power factor 1.0 (at any load condition).
INVERTER
Nominal voltage Three phase 3x380 V, 3x400 V or 3x415 V (4 wires: 3 phases + N).
Precision Static variation: ±1 %. Dynamic variation: ±2 % (load variations 100%-0%-100 %).
Frequency Synchronised: 50/60 Hz ±4 % / Battery mode 50/60 Hz ±0.05 %.
Max. synchronisation speed ±1 Hz/s.
Wave form Sine-wave.
Output voltage total harmonic
distortion
Linear load: THD-v < 0.5 %. Ref. non-linear load (EN-62040-3): THD-v < 1.5 %.
Phase displacement 120 ±1 % (balanced load). 120 ±2 % (imbalances 50 % of the load).
Dynamic recovery time 10 ms. at 98 % of the static value.
Admissible overload 125 % for 10 min., 150 % for 60 s.
Admissible crest factor 3.4 to 1. 3.2 to 1. 2.8 to 1.
Admissible power factor 0.1 inductive to 0.1 capacitive.
Imbalance output voltage with load
100 % unbalanced
< 1 %.
Current limit High overload, short-circuit: RMS voltage Limit. High Crest-Factor current: Peak Voltage Limit.
STATIC BYPASS
Type Microprocessor-controlled static system
Voltage Three phase 3x380 V, 3x400 V or 3x415 V (4 wires: 3 phases + N).
Frequency 50 / 60 Hz
Transfer time Zero
Admissible overload 400 % for 10 sec.
Transfer to bypass Immediate, for overloads above 150 %.
Retransfer Automatic after alarm clear.
MANUAL BYPASS (maintenance)
Type Without interruption.
Voltage Three phase 3x380 V, 3x400 V or 3x415 V (4 wires: 3 phases + N).
Frequency 50 / 60 Hz.
GENERAL
Overall efficiency 90.5 % 90.5 % 91.0 % 92.0 % 92.5 % 93.05 % 94.0 %
DIMENSIONS & WEIGHT (cabinet ups)
Depth x Width x Height (mm) /
equipped with castors
700 x 450 x 1100 / YES. 805 x 590 x 1320 / YES.
Weight (no batteries) (kg) 120 190 200 300
Built-in 2x31 batteries 12 V (Ah) 7 7 9 12 18 - -
Weight (with built-in batteries) (kg) 250 530 - -
Batteries terminal torque Depending on battery manufacture.
Table 5. Technical specifications
