Ethernet Settings
USB-HID Setting
USB-CDC Setting
Tailgate Settings
Bluetooth Settings
To reverse the steps taken in any of the above menus, and go back to the Telium Manager main menu, press the red [X] keypad
button, then press the [+] or [F] keypad button.
If the communication port settings are changed, press the [CANCEL] key several times in the Save and Reboot menu. Then select
[YES] to save changes.
6_1_1 RS-232 (Serial) Setting
To view serial port settings, select the [CONFIGURATION] option from the Telium Download Application menu and follow the
subsequent selections as illustrated in the below figure. By selecting these options you will be able to view baud rate, stop bit, bits per
byte, parity, and flow control settings.
To change baud rate, follow the menu selection as illustrated below. In the below example, a baud rate of 115,200 (default) is
selected.
To change bits per byte, from the SERIAL SETTINGS menu proceed as follows:
