2.
3.
4.
Place the iSC250 in front of you with the bottom of the terminal facing up. Be careful not to place the device on a surface
where the display screen can be scratched or damaged.
If you have secured the cable with screws, carefully remove the two screws from either side of the Multipoint cable.
Carefully pull out the Multipoint cable using the loop as shown in the below image.
7_3 iSC350 Quick Reference
The iSC350 Quick Reference is organized into the following sections:
iSC350 Overview
iSC350 Power Requirements
iSC350 Secure Access Modules
iSC350 Peripheral Connectors and Host Interface Options
7_3_1 iSC350 Overview
The iSC350 device can communicate with a host device such as a POS or PC via RS-232, Tailgate (RS-485), USB or Ethernet
interfaces. This terminal features a stylus, optional integrated contactless card reader, smart card reader, and MSR as shown in the
below image.
