©2008 Ingersoll Rand Company Page 45
times out and shuts off then this timer needs to
be adjusted to a longer time span. This timer is
adjustable from 1 - 30 seconds.
Condensate Interval Timer
This timer is adjustable from 90 - 300 seconds
and it is set to tell the controller when to
energize the electronic drain valve.
Service Due Timer
This screen allows the service technician to
adjust the service timer. The timer can be
adjusted from 0 – 2000.
Scheduled Start and Stop
This screen allows the service technician to turn
on or off the scheduled start and stop option.
This screen will only be visible in the enhanced
version of the controller.
Scheduled Start Time
If the scheduled start/ stop option has been
turned on, then this screen will be available to
allow the technician to set a time for the
compressor to automatically turn itself on. This
time can be set for any time between 0 – 24
hours. NOTE: This is a seven-day a week timer
and will start the compressor everyday at the
same time.
Scheduled Stop Time
This screen will be viewable if the scheduled
start/stop option has been turned on. This
