General information 7
Programming manual
Left, right, behind, above, below: indications using the operator's
position in front of the mounted device as the reference point.
Pulse output: same as "monostable output"
Dialler (phone, SMS, digital): same as "communicator"
Qualified personnel: those persons whose training, expertise and
knowledge of the respective laws and bylaws regarding service conditions
and the prevention of accidents, are able to identify and avoid all possible
situations of danger.
Click on: click to select a specific item (from drop-down menu, options box,
graphic object, etc.).
Select: click on a video button.
2.6.2 Graphic key
Text in italics: indicates the title of a chapter, section, paragraph, table or
figure in this manual or other published reference.
<text>: editable space, for example #<CustomerCode># may become
#0001#.
[Uppercase letters] (e.g..[A]): indicate the device parts or video objects.
Note: The detached notes contain important information about
the respective text.
Attention: The attention prompts indicate that total or partial
disregard of the procedure could damage the
connected devices.
Danger: The danger warnings indicate that total or partial
disregard of the procedure could injure the operator
or persons in the vicinity.
