12 Programming the SmartLink-GP
Programming manual
3.3.5 Status enquiry
1. Connect the computer to the RS232 serial port of the device.
2. Select Control panel, Status enquiry: a window appears showing the
IMEI code, SIM data, installed version and battery, GSM network and
input statuses.
3. Select Send SMS, to send an SMS Test text from the SmartLink.
3.3.6 Viewing the Events log
1. Connect the computer to the RS232 serial port of the device.
2. Create a new solution (select File, New), or open the current solution
(configuration) of the system (select File, Open).
3. To view the contents of the events log, select Log.
4. Select the icon. The recorded events will appear on the bottom left.
5. The recorded events appear.
Note: The contents of the event log can be printed or saved to the
database.
3.3.7 Print
1. Define the printout header (e.g. Logo, Company name, etc.).
2. To type in the respective data, select Printer settings, from Settings,
Application settings.
3. Select the icon and click on the file you wish to print.
3.4 Recommended programming flow
Due to the flexibility-optimized SmartLink-GP software, many ways of
preparing the parameters exist, depending on the type of application.
Generally, you can proceed as follows.
1. Prepare the data:
• phone numbers for Contact ID reports, SMS texts and voice messages
• SMS text messages
• voice messages
• Caller ID codes
2. Configure the device parameters
3. Configure the inputs and outputs (for intrusion control and reserve line
applications).
4. Associate the incoming/outgoing calls with specific actions.
5. Program the events which will:
• Send pre-set SMS text messages
• Send Contact ID reports
• Send voice messages
