NV9 USB Manual Set – Section 1 5
Copyright © Innovative Technology Ltd 2012 GA00550-2
6. The cashbox housing is
mounted in the host machine
with the NV9 USB mounted
on top. The cashbox is then
slid into the housing until it is
securely clipped.
7. If the validator is fitted with
an NV11 standard cashbox,
then the validator will be
mounted HORIZONTALLY
8. The validator will be fitted
with a suitable horizontal
bezel
9. The cashbox is attached to
the validator by locating and
sliding until the cashbox is
clipped securely
