The bezel is refitted by pushing the bezel back onto the locating pins and sliding
backwards until all six pins are engaged in the slots. The locking arms will then spring
back and locate into the bezel.
Caution!
Check locking arms.
Always make sure that BOTH locking arms are
fully located in the bezel – trying to operate the
validator if they are not correctly located can
cause unit damage.
1.3 Interfacing
The connector needed to set up and interface the NV9 USB Validator is easily
accessible on the side of the unit:
Interface Socket
