Inovance IS300 Series Troubleshooting Instructions

Chapter2TechnicalSpecificationsandElectricalInstallation

6
Chapter 2 Technical Specifications and Electrical Installation
2.1 IS300 Servo Drive Models and Specifications
Motor Power (S1)
Servo Drive Model
Power
Capacity
(kVA)
Input
Current
(A)
Output
Current
(A)
kW HP
Single-phase 220–230 V, 50/60 Hz
IS300S002-C 1 5.4 2.3 0.4 0.5
IS300S003-C 1.5 8.2 4 0.75 1
IS300S004-C 3 14 7 1.5 2
IS300S005-C 4 23 9.6 2.2 3
Three-phase 220 V, 50/60 Hz
IS300-2T002-C 1.5 3.4 2.1 0.4 0.5
IS300-2T003-C 3 5 3.8 0.75 1
IS300-2T004-C 4 5.8 5.1 1.5 2
IS300-2T005-C 5.9 10.5 9 2.2 3
IS300-2T010-C 8.9 14.6 13 3.7 5
IS300-2T020-C 17 26 25 5.5 7.5
IS300-2T030-C 21 35 32 7.5 10
IS300-2T040-C 30 46.5 45 11 15
IS300-2T050-C 40 62 60 15 20
IS300-2T070-C 57 76 75 18.5 25
IS300-2T080-C 69 92 91 22 30
IS300-2T100-C 85 113 112 30 40
IS300-2T140-C 114 157 150 37 50
IS300-2T170-C 134 180 176 45 60
IS300-2T210-C 160 214 210 55 75
IS300-2T300-C 231 307 304 75 100
IS300-2T140-C-L 114 157 150 37 50
IS300-2T170-C-L 134 180 176 45 60
IS300-2T210-C-L 160 214 210 55 75
IS300-2T300-C-L 231 307 304 75 100
Three-phase 380–440 V, 50/60 Hz
IS300T002-C 1.5 3.4 2.1 0.75 1
IS300T003-C 3 5 3.8 1.5 2
IS300T004-C 4 5.8 5.1 2.2 3
IS300T005-C 5.9 10.5 9 3.7 5
IS300T010-C 8.9 14.6 13 5.5 7.5
IS300T015-C 11 20.5 17 7.5 10
