Chapter2TechnicalSpecificationsandElectricalInstallation
8
Motor Power (S1)
Servo Drive Model
Power
Capacity
(kVA)
Input
Current
(A)
Output
Current
(A)
kW HP
IS300-5T140-C 114 157 150 75 100
IS300-5T170-C 134 180 176 90 125
IS300-5T210-C 160 214 210 110 150
IS300-5T250-C 192 256 253 132 175
IS300-5T300-C 231 307 304 160 210
IS300-5T370-C 250 385 377 200 260
IS300-5T420-C 280 430 426 220 300
IS300-5T460-C 355 468 465 250 350
IS300-5T520-C 396 525 520 280 370
IS300-5T580-C 445 590 585 315 420
IS300-5T650-C 500 665 650 355 470
IS300-5T720-C 565 785 725 400 530
IS300-5T140-C-L 114 157 150 75 100
IS300-5T170-C-L 134 180 176 90 125
IS300-5T210-C-L 160 214 210 110 150
IS300-5T250-C-L 192 256 253 132 175
IS300-5T300-C-L 231 307 304 160 210
2.2 Selection of Braking Unit and Braking Resistor
IS300 Model
Recommended Power
of Braking Resistor
Recommended
Resistance
Braking
Unit
Remarks
Single-phase 220–230 V
IS300S002-C 80 W 200
IS300S003-C 80 W 150
IS300S004-C 100 W 100
IS300S005-C 100 W 70
Built-in -
Three-phase 220 V
IS300-2T002-C 150 W 150
IS300-2T003-C 150 W 110
IS300-2T004-C 250 W 100
IS300-2T005-C 300 W 65
IS300-2T010-C 400 W 45
IS300-2T020-C 800 W 22
IS300-2T030-C 1000 W 16
IS300-2T040-C 1500 W 11
IS300-2T050-C 2500 W 8
Built-in -
IS300-2T070-C 3.7 kW 8 External MDBUN-45-S
IS300-2T080-C 4.5 kW 8 External MDBUN-60-S
IS300-2T100-C 5.5 kW 6 External MDBUN-60-S
To Next Page
