Chapter2TechnicalSpecificationsandElectricalInstallation

9
IS300 Model
Recommended Power
of Braking Resistor
Recommended
Resistance
Braking
Unit
Remarks
IS300-2T140-C 7.5 kW  6  External MDBUN-60-S
IS300-2T170-C 9 kW  4  External MDBUN-90-S
IS300-2T210-C 11 kW  4  External MDBUN-90-S
IS300-2T300-C 8 x 2 kW  6  x 2 External MDBUN-60-S x 2
IS300-2T140-C-L 7.5 kW  6  External MDBUN-60-S
IS300-2T170-C-L 9 kW  4  External MDBUN-90-S
IS300-2T210-C-L 11 kW  4  External MDBUN-90-S
IS300-2T300-C-L 8 x 2 kW  6  x 2 External MDBUN-60-S x 2
Three-phase 380–440 V
IS300T002-C 150 W  300 
IS300T003-C 150 W  220 
IS300T004-C 250 W  200 
IS300T005-C 300 W  130 
IS300T010-C 400 W  90 
IS300T015-C 500 W  65 
IS300T020-C 800 W  43 
IS300T030-C 1000 W  32 
IS300T035K-C 1300 W  25 
IS300T035-C 1300 W  25 
IS300T040-C 1500 W  22 
IS300T050-C 2500 W  16 
IS300T070K-C 3.7 kW  16 
Built-in -
IS300T070-C 3.7 kW  16  External MDBUN-45-T
IS300T080-C 4.5 kW  16  External MDBUN-45-T
IS300T100-C 5.5 kW  16  External MDBUN-45-T
IS300T140K-C 6.5 kW  12  External MDBUN-60-T
IS300T140-C 7.5 kW  12  External MDBUN-60-T
IS300T170-C 9 kW  8  External MDBUN-90-T
IS300T210-C 5.5 kW x 2  12  x 2 External MDBUN-60-T x 2
IS300T250-C 6.5 kW x 2  8  x 2 External MDBUN-90-T x 2
IS300T300-C 16 kW  2.5  External MDBU-200-B
IS300T370-C 20 kW  2.5  External MDBU-200-B
IS300T420-C 22 kW  2.5  External MDBU-200-B
IS300T460-C 12.5 kW x 2  2.5  x 2 External MDBU-200-B x 2
IS300T520-C 14 kW x 2  2.5  x 2 External MDBU-200-B x 2
IS300T580-C 16 kW x 2  2.5  x 2 External MDBU-200-B x 2
IS300T650-C 17 kW x 2  2.5  x 2 External MDBU-200-B x 2
IS300T720-C 14 kW x 3  2.5  x 3 External MDBU-200-B x 3
IS300T140-C-L 7.5 kW  8  External MDBUN-90-T
IS300T170-C-L 11 kW  8  External MDBUN-90-T
IS300T210-C-L 5.5 kW x 2  12  x 2 External MDBUN-60-T x 2
