Chapter2TechnicalSpecificationsandElectricalInstallation

10
IS300 Model
Recommended Power
of Braking Resistor
Recommended
Resistance
Braking
Unit
Remarks
IS300T250-C-L 6.5 kW x 2  8  x 2 External MDBUN-90-T x 2
IS300T300-C-L 16 kW  2.5  External MDBU-200-B
Three-phase 480 V
IS300-5T002-C 150 W  300 
IS300-5T003-C 150 W  220 
IS300-5T004-C 250 W  200 
IS300-5T005-C 300 W  130 
IS300-5T010-C 400 W  90 
IS300-5T015-C 500 W  65 
IS300-5T020-C 800 W  43 
IS300-5T030-C 1000 W  32 
IS300-5T035-C 1300 W  25 
IS300-5T040-C 1500 W  22 
IS300-5T050-C 2500 W  16 
Built-in -
IS300-5T070-C 3.7 kW  16  External MDBUN-45-5T
IS300-5T080-C 4.5 kW  16  External MDBUN-45-5T
IS300-5T100-C 5.5 kW  16  External MDBUN-45-5T
IS300-5T140-C 7.5 kW  12  External MDBUN-60-5T
IS300-5T170-C 9 kW  8  External MDBUN-90-5T
IS300-5T210-C 11 kW  8  External MDBUN-90-5T
IS300-5T250-C 6.5 kW x 2  12  x 2 External MDBUN-60-5T x 2
IS300-5T300-C 16 kW  2.5  External MDBU-200-D
IS300-5T370-C 20 kW  2.5  External MDBU-200-D
IS300-5T420-C 22 kW  2.5  External MDBU-200-D
IS300-5T460-C 12.5 kW x 2  2.5  x 2 External MDBU-200-D x 2
IS300-5T520-C 14 kW x 2  2.5  x 2 External MDBU-200-D x 2
IS300-5T580-C 16 kW x 2  2.5  x 2 External MDBU-200-D x 2
IS300-5T650-C 17 kW x 2  2.5  x 2 External MDBU-200-D x 2
IS300-5T720-C 14 kW x 3  2.5  x 3 External MDBU-200-D x 3
IS300-5T140-C-L 7.5 kW  12  External MDBUN-60-5T
IS300-5T170-C-L 9 kW  8  External MDBUN-90-5T
IS300-5T210-C-L 11 kW  8  External MDBUN-90-5T
IS300-5T250-C-L 6.5 kW x 2  12  x 2 External MDBUN-60-5T x 2
IS300-5T300-C-L 16 kW  2.5  External MDBU-200-D
1. " x 2" indicates that two braking units with their respective braking resistor are connected in parallel. " x
3" means the same.
2. The models in grey are customized (servo drive of water cooling).
