1.1.3 During wiring:
Danger
z Operation shall be performed by the professional engineering technician.
Otherwise there will be danger of electric shock!
z There shall be circuit breaker between the servo driver and power
supply. Otherwise, there may be fire!
z Make sure the power is disconnected prior to the connection.
Otherwise there will be danger of electric shock!
z The earth terminal shall be earthed reliably. Otherwise there may be
danger of electric shock.
z 6．Do not connect the input power cable to the output ends U, V and W.
Otherwise it may damage the servo driver.
z 7. Ensure the wiring meet the EMC requirements and the local safety
standard. The wire size shall be determined according to the manual.
Otherwise, accident may be caused!
z 8. The brake resistor cannot be directly connected between the DC bus
terminals (+) and (-). Otherwise it may cause fire.
1.1.4 Before Power-on：
Danger
z Before Power-on:
z Please confirm whether the power voltage class is consistent with the
rated voltage of the servo driver and whether the I/O cable connecting
positions are correct, and check whether the external circuit is short
circuited and whether the connecting line is firm. Otherwise it may
damage the servo driver!
z The cover must be well closed prior to the servo driver power-on.
Otherwise electric shock may be caused!
