Chapter 1 Product Information
-
10
-
Table 1-1Models of switching-mode power supply
Component Quantity Adapted Model Remarks
Switching-
mode power
supply
1
ECU EPR-35-24
EPR-35-24
(35W，DC24V)
Schneider
ABL2REM24015H
(35W，DC24V)
Mean Well
LRS-35-24
(35W，DC24V)
The switching-
mode power
supply of
MCTC-
PES-E1 is
provided by
Monarch.
Table 1-2 Models of sensors and detection switches
Accessory Quantity Recommended Model Remarks
Sensor Schneider OMRON
Specify the required
sensor models in
your order. Monarch
will deliver them
(except NBN40-L2-
E0-V1) together with
the MCTC-PES-E1.
Both low-level and
high-level signals
are supported.
Escalator/Moving
walkway speed
sensor
2 XS2 18BLNAL2C
E2B-M18KN16-WP-C1-
MNK
Handrail speed
sensor
2 XS2 12BLNAL2C
E2B-M12KN08-WP-C1-
MNK
Step loss
detection sensor
2 XS2 30BLNAL2C
E2B-M30KN20-WP-C1-
MNK、E2B-M30LN30-
WP-C1-MNK
Detection Switch Schmersal OMRON
Customer option
Motor brake
detection switch
2
TS236-02Z
TS236-11Z
D4N-4132
D4NA-4131
Auxiliary brake
detection switch
1
TS236-02Z
TS236-11Z
D4N-4132
Floor plate
detection switch
4
TS236-02Z
TS236-11Z
D4N-4132
D4N-2B64-E1
D4NA-412G
1.3 System Functions
The MCTC-PES-E1 is designed to ensure safe running of escalator and moving walkway
according to the security grading defined in the newest escalator security standard
GB16899-2011. It has the following security functions:
■
Overspeed protection
■
Unintentional reversal protection
■
Handrail speed deviation protection
■
Service brake and auxiliary brake monitoring protection
■
Step or pallet loss protection
■
Braking-to-stop distance detection and alarm
■
Floor plate state monitoring
