Chapter 4 Functional Parameters
-
39
-
F2-20
Input state 2 at latest
fault
- - - ●
F2-21
Output state at latest
fault
- - - ●
F2-22
Phase A escalator
speed at latest fault
- - - ●
F2-23
Phase B escalator
speed at latest fault
- - - ●
F2-24
Detected running
direction at latest
fault
- - - ●
F2-25
Left handrail pulse
time interval at latest
fault
- - - ●
F2-26
Right handrail pulse
time interval at latest
fault
- - - ●
F2-19 records the state of input terminals X1 to X16 when the latest fault occurs. Each
terminal is allocated with a bit. The corresponding relationship is as follows:
Bit0: X1; Bit1: X2; …… Bit15: X16
F2-20 records the state of input terminals X17 to X20 when the latest fault occurs. Each
terminal is allocated with a bit. The corresponding relationship is as follows:
Bit0: X17 Bit1: X18; Bit2: X19; Bit3: X20
F2-21 records the state of relays Y1 and Y3. Each relay is allocated with a bit. The
corresponding relationship is as follows:
Bit0: Y1; Bit1: Y1F; Bit2: Y3; Bit3: Y3F
F2-22 and F2-23 record the phase A/B escalator speed when the latest fault occurs. The
actual record is phase A/B pulse cycle (unit: 10 ms) or the number of phase A/B pulses a
second. They can be determined based on F2-10, F2-11 and F2-12.
Group FF: Factory Parameters
Group FP: Management Parameters
Parameter Name Setting Range Factory Setting Unit Operation
FP-00 User password 0–6553 0 - ★
FP-01 Software version 0–6553 - - ●
FP-02 Reserved - - - ●
