Chapter 4 Functional Parameters
-
34
-
Group F1: State Parameters
Parameter Name Setting Range Factory Setting Unit Operation
F1-00
Phase A escalator
speed
- 0 m/s
●
F1-01
Phase B escalator
speed
- 0 m/s
●
They indicate the escalator speed respectively, detected by sensor A and sensor B.
Parameter Name Setting Range Factory Setting Unit Operation
F1-02
Number of phase
A pulses/cycles for
escalator speed
- 0 -
●
F1-03
Number of phase
B pulses/cycles for
escalator speed
- 0 -
●
If the number of phase A/B pulses per second at nominal speed (F0-01) is equal to or
larger than 30, F1-02 and F1-03 display the actually detected number of phase A/B pulses.
If their value is smaller than 30, the phase A/B cycles is displayed by a 3-digit decimal in
the unit of second.
Parameter Name Setting Range Factory Setting Unit Operation
F1-04
Current running
direction
- 0 -
●
It displays the escalator speed signal state. The 5-digit display is abcde from left to right.
Display Description
a
0 indicates that the direction is not given.
1 indicates that the startup command in upward direction is given.
2 indicates that the startup command in downward direction is given.
b
0 indicates that the feedback signal is abnormal.
1 indicates that the feedback running direction is upward.
2 indicates that the feedback running direction is downward.
c, d Reserved
e
It represents the orthogonality. 0 indicates the worst, and 9 indicates the best.
Ensure the value above 5 by adjusting the position of the two speed sensors.
The parameter has three normal values: 00000, 11009 and 22009.
Parameter Name Setting Range Factory Setting Unit Operation
F1-05
Braking-to-stop
distance after stop
- 0 m
●
