Instron 34SC-5 User Manual

Chapter: Introduction
16 M10-17313-EN
Legend for Figure 1
Label Component
1Ballscrew cover
2Top plate
3Column cover
4Load cell
5Upper limit switch
6 Limit switch actuator
7Lower limit switch
8 Emergency stop button
9 Frame control panel
10 Bluehill
®
Operator Dashboard (optional)

Instron 34SC-5 Specifications

General

Brand	Instron
Model	34SC-5
Category	Test Equipment
Language	English
