Chapter: Installation
38 M10-17313-EN
Single column load frame
Figure 5. Frame connections
Legend for Figure 5
5
2
4
3
8
6
10
9
7
11
1
Label Component More detail
1 Mains cable and plug
2 Ground connectiton (when required) “Ground connection detail”
on page 42
