Before you begin
Product Support: www.instron.com
Before you begin
Check the following before installing a load cell:
You have all the parts required for installation. Refer to the appropriate figure for
your load cell in “Install the load cell” on page 76.
Mounting screws are lubricated.
A torque wrench is available.
All threads, bores and mating surfaces are clean and free of damage.
2519-500N 500 N (112) 88.5 (3.48) 6 mm clevis pin Of
2519-1KN 1 kN (225) 88.5 (3.48) 6 mm clevis pin Of
2519-2KN 2 kN (450) 101.2 (3.98) 6 mm clevis pin Of
2519-5KN 5 kN (1125) 114 (4.5) 12.5 mm clevis pin Df
Table 8. 2519 Series (Continued)
Catalog no.
Capacity
N (lbf)
Effective length
mm (in) Mechanical fitting Interface size
Table 9. 2530 Series
Catalog no.
Capacity
N (lbf)
Effective length
mm (in) Mechanical fitting Interface size
2530-5N 5 N (1) 48 (1.89) 2.5 mm clevis pin
and 6 mm clevis pin
OOf
Of
2530-10N 10 N (2.25) 48 (1.89) 2.5 mm clevis pin
and 6 mm clevis pin
OOf
Of
2530-50N 50 N (11) 48 (1.89) 2.5 mm clevis pin
and 6 mm clevis pin
OOf
Of
2530-100N 100 N (22) 48 (1.89) 2.5 mm clevis pin
and 6 mm clevis pin
OOf
Of
2530-500N 500 N (112) 91 (3.58) 6 mm clevis pin Of
2530-1KN 1 kN (225) 91 (3.58) 6 mm clevis pin Of
2530-2KN 2 kN (450) 91 (3.58) 6 mm clevis pin Of
2530-5KN 5 kN (1125) 101 (3.98) 12.5 mm clevis pin Df
