Level the load frame
Level the load frame immediately after you position it for installation. This prevents the
base from rocking and provides a level test surface for more accurate results.
Refer to Figure 3 on page 31 and follow the procedure.
Figure 3. Adjust the leveling feet
You need the following equipment (supplied in the ancillary parts kit unless specified
otherwise):
1
2
