Instron 6800 Series User Manual

Chapter: Introduction
16 M10-17410-EN
Legend for Figure 1
Label Component
1Ballscrew cover
2Top plate
3Column cover
4Load cell
5Upper limit switch
6 Limit switch actuator
7Lower limit switch
8 Emergency stop button
9 Indicator panel
10 Bluehill
®
Operator Dashboard (optional)
11 Handset

Instron 6800 Series Specifications

General

Brand	Instron
Model	6800 Series
Category	Test Equipment
Language	English
