Instron 6800 Series User Manual

Chapter: Installation
38 M10-17410-EN
Single column load frame
Figure 5. Frame connections
Legend for Figure 5
5
2
4
3
8
6
10
9
7
11
1
Label Component More detail
1 Mains cable and plug
2 Ground connectiton (when required) “Ground connection detail”
on page 42
3To Bluehill
®
Operator Dashboard or
separate computer (not shown in
Figure 5)
4 System ID label
