Instron 68TM-5 - Environmental Specifications; General

Chapter: Requirements
28 M10-17416-EN
Dry compressed air
A dry, compressed air supply regulated to a maximum pressure of 8.3 bar (120 psi) is
required for the integrated air kit. The regulated supply pressure must be greater than
the test pressure value set in Bluehill
®
software.
The customer is responsible for adapting the pneumatic connection of the integrated air
kit to their supply. Instron
®
provides a 0.25 inch (6.3 mm) outer diameter, 0.125 inch
(3.2 mm) inner diameter tube, which can be connected using an appropriately sized
hose barb, compression or push-to-connect fitting. A 0.25 inch (6.3 mm) NPT male to
push-to-connect fitting is also supplied.
Water supply
A water supply may be required for some specimen grips and some temperature control
systems.
Liquid nitrogen and carbon dioxide
A liquid nitrogen (LN2) or carbon dioxide (CO2) supply may be required for
environmental chambers with cooling options.
For carbon dioxide, tank pressure must be approximately 725 psi. It must be in a liquid
state when it reaches the valve of the environmental chamber.
For liquid nitrogen, tank pressure must be between 5 and 10 psi, depending upon the
regulator and relief valves that are fitted to the dewar flask. Do not exceed 20 psi.
Environmental specifications
General
Table 4. Environmental specifications
Parameter Specifications
Operating
Temperature
+5°C to +40°C (+41°F to +104°F)
Storage
Temperature
-25°C to +55°C (-13°F to +131°F)
Humidity 10% to 90% (non-condensing)
