Chapter 3
Specifications
• 68TM-5 Dimensions and Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
• Accessory Mounting Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
• System Performance. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
68TM-5 Dimensions and Weight
Frame Dimensions
Load frame dimensions for 68TM-5 frames are shown in Figure 3 on page 37 and
Figure 4 on page 38.
For those dimensions shown as labels in the figures, Table 7 on page 35 lists them for
standard height frames and Table 8 on page 36 lists them for extra height frames.
Dimension “F” in Figure 3 on page 37 varies for different load cells, refer to Table 9 on
page 36.
Figure 5 on page 39 shows the overall dimensions of the system including the
Bluehill
®
Operator Dashboard.
Table 7. 68TM-5 dimensions - standard height
Letter
Designation Description Dimension - mm (inch)
A Overall height 1638 (64.5)
E2 Maximum vertical test space (test daylight - from
base to underside of crosshead)
1234 (48.6)
E1 Minimum vertical test space (test daylight - from
base to underside of crosshead)
71 (2.8)
B Overall width 756 (29.8)
