Chapter: Specifications
36 M10-17416-EN
D Horizontal test space (space between columns) 420 (16.5)
J Crosshead thickness 76 (3.0)
R Top plate thickness 57 (2.24)
T Top plate width 180 (7.09)
U Top plate length 721 (28.4)
Table 7. 68TM-5 dimensions - standard height (Continued)
Letter
Designation Description Dimension - mm (inch)
Table 8. 68TM-5 dimensions - extra height
Letter
Designation Description Dimension - mm (inch)
A Overall height 2163 (85.2)
E2 Maximum vertical test space (test daylight - from
base to underside of crosshead)
1739 (68.5)
E1 Minimum vertical test space (test daylight - from
base to underside of crosshead)
91 (3.6)
B Overall width 756 (29.8)
D Horizontal test space (space between columns) 420 (16.5)
J Crosshead thickness 76 (3.0)
R Top plate thickness 57 (2.24)
T Top plate width 180 (7.09)
U Top plate length 721 (28.4)
Table 9. Dimension “F” - crosshead to load cell clevis pin hole
Load cell capacity Connection type Distance - mm (inch)
500N, 1kN, 2kN O 91 (3.58)
5 kN D 101 (3.98)
10 kN, 30 kN, 50 kN D 122 (4.80)
