Chapter: Specifications
40 M10-17416-EN
System weight
The weight value does not include additional accessories such as the Bluehill
®
Operator
Dashboard or any load cell.
The weight of the Bluehill
®
Operator Dashboard and its mounting kit is 2.4 kg (5.2 lb).
Accessory Mounting Dimensions
You can attach numerous testing accessories and fixtures to the load frame for
specialized tests. Use the standard mounting holes shown in the following diagrams to
mount your accessories. Avoid tapping new holes that may weaken or otherwise
compromise the integrity of the load frame.
All measurements in the following figures are shown in mm.
Table 10. System weight
Configuration Weight kg (lb)
Standard height load frame 139.3 (307)
Extra height load frame 154.2 (340)
Table 11. Meaning of symbols on dimension drawings
Symbol on drawing Meaning
diameter
depth
THRU through-hole
LH left hand thread
RH right hand thread
PCD pitch circle diameter
