Integra DTC-9.8 - Specifications

129
Specifications
Amplifier Section
Video Section
Tuner Section
■ FM
■ AM
■ Digital Tuner
General
■ Video Input
■ Video Output
■ Audio Inputs
■ Audio Outputs
■ Control Terminal
Specifications and features are subject to change without
notice.
THD (Total Harmonic
Distortion) 0.05% (1 Vrms)
Input Sensitivity and
Impedance 200 mV/ 47 k
Ω (LINE)
2.5 mV/47 k
Ω (PHONO MM)
Output Level and
Impedance 200 mV/ 470
Ω (REC OUT)
Phono Overload 70 mV (MM 1 kHz, 0.5%)
Frequency Response 5 Hz–100 kHz/ +1 dB–3 dB (Direct mode)
Tone Control ±10 dB, 20 Hz (BASS)
±10 dB, 20 kHz (TREBLE)
Signal to Noise Ratio 110 dB (LINE, IHF-A)
80 dB (PHONO, IHF-A)
Input Sensitivity/Output
Level and Impedance 1 Vp-p /75
Ω (Component and S-Video Y)
0.7 Vp-p /75
Ω (Component Pb/Cb,Pr/Cr)
0.28 Vp-p /75
Ω (S-Video C)
1 Vp-p /75
Ω (Composite)
Component Video
Frequency Response 5 Hz – 100 MHz, –3 dB
Tuning Frequency Range
North American: 87.5 MHz– 107.9 MHz
Australian: 87.5 MHz– 108.0 MHz
Tuning Frequency Range
North American: 530 kHz–1710 kHz
Australian: 522 kHz–1611 kHz
North American: XM, SIRIUS, HD RADIO
Preset Channel 40
Power Supply AC 120 V, 60 Hz
AC 220-240 V, 50/60 Hz
Power Consumption
North American: 1.1 A
Australian: 85 W
Dimensions
(W
× H × D) 435 × 194 × 444.5 mm
17-1/8" × 7-5/8" × 17-1/2"
Weight 13.3 kg
29.3 lbs.
HDMI IN 1, IN 2, IN 3, IN 4
Component IN 1 (DVD), IN 2, IN 3
Composite AUX 1, GAME/TV, CBL/SAT,
VCR/DVR, DVD, AUX 2
S-Video AUX 1, GAME/TV, CBL/SAT,
VCR/DVR, DVD, AUX 2
HDMI OUT (MAIN), OUT (SUB)
Component MONITOR OUT 1, MONITOR OUT 2
Composite VCR/DVR OUT, MONITOR OUT
S-Video VCR/DVR OUT, MONITOR OUT
Digital Inputs COAXIAL IN 1, IN 2, IN 3,
OPTICAL IN 1, IN 2, IN 3 (Front)
Analog Inputs PHONO, CD, TAPE, AUX 1, GAME/TV,
CBL/SAT, VCR/DVR, DVD, MULTI CH
(FRONT, CENTER, SUBWOOFER,
SURR, SURR BACK), AUX 2
Multichannel Inputs 7.1 ch
Digital Output OPTICAL (OUT)
Analog Outputs TAPE, VCR/DVR, PRE OUT (FRONT,
CENTER, SUBWOOFER, SURR, SURR
BACK, ZONE 2, ZONE 3)
Balance Pre Outputs FL, FR, C, SL, SR, SBL, SBR, SW
Multichannel Pre
Outputs 7
Subwoofer Pre Outputs 1
Phones PHONES
MIC Yes
RS232 1
Ethernet 1
IR Input/Output 2/1
12 V Trigger Out 3
