14
Getting to Know the AV Controller
—Continued
Z
GAME/TV IN
A game console or TV output can be connected
here. There’s S-Video and composite video input
jacks for connecting the video signal.
a
CBL/SAT IN
A cable or satellite receiver can be connected here.
There’s S-Video and composite video input jacks
for connecting the video signal.
b
VCR/DVR IN/OUT
A video component, such as a VCR or DVR, can be
connected here for recording and playback. There’s
S-Video and composite video input and output jacks
for connecting the video signal.
c
DVD IN
This input is for connecting a DVD player. There’s
S-Video and composite video input jacks for con-
necting the video signal.
d
FRONT L/R, CENTER, SURR L/R, SURR
BACK L/R, and SUBWOOFER PREOUT
These balanced XLR outputs are for connecting a
multichannel power amplifier and powered sub-
woofer.
The FRONT L/R and SURR BACK L/R outputs can
be used with front speakers and surround back
speakers, respectively, or used to bi-amp the front
speakers. See “Bi-amping the Front Speakers” on
page 25.
e
MULTI CH input: FRONT L/R, CENTER,
SUBWOOFER, SURR L/R, and SURR BACK
L/R
This analog multichannel input is for connecting a
component with a 5.1/7.1-channel analog audio out-
put, such as a DVD player, DVD-Audio or
SACD-capable player, or an MPEG decoder.
f
PRE OUT: FRONT L/R, CENTER, SUB-
WOOFER, SURR L/R, and SURR BACK L/R
This 5.1/7.1 multichannel analog audio output can
be connected to the analog audio input on a multi-
channel power amplifier for when you want to use
the AV controller solely as a preamplifier. The SUB-
WOOFER jack is for connecting a powered sub-
woofer.
g
PRE OUT: ZONE 2, ZONE 3
These analog audio outputs can be connected to the
line inputs on amplifiers in Zone 2 and Zone 3. The
SW jacks can be connected to the inputs on pow-
ered subwoofers in Zone 2 and Zone 3.
h
AC OUTLET (North American model only)
These switched AC outlets can be used to supply
power to other AV components. The type and num-
ber of outlets depends on the country in which you
purchased your AV controller.
See pages 21–44 for hookup information.
DTC-9.8En.book Page 14 Friday, February 15, 2008 1:23 PM
To Next Page
