9
R
R
R
A100 838440089GR 4TTB+8C(3BC),Screw
A101 838430088GR 3TTB+8B(3CM),Screw
A105 801618 3TTB+8B(CU)SR,Screw
A110 29364345 Label PT
A111 27175418 Leg
A114 838430088GR 3TTB+8B(3BC),Screw
A115 27255004 CS-1U,Clip
A119 28141647 Cushion
A401 27123486 Rear panel
A402 838430088GR 3TTB+8B(3BC),Screw
A405 838440089GR 4TTB+8C(3BC),Screw
A409 27270463
T0.5*Φ8*Φ3.5,Spacer
A410 27212846 Front panel
A420 29363195 Label, hookup
F6901,F6
252301G ! 12A-TUL-250V,Fuse
F901 252330G
! 10A-UL/T-233,Fuse
F903 252326G
! 5A-UL/T-233,Fuse
