Integra DTR-7.2 User Manual

21
Connecting a subwoofer
Use the PRE OUT SUBWOOFER jack to connect a subwoofer with
a built-in power amplifier. If your subwoofer does not have a built-in
amplifier, connect an amplifier to the PRE OUT SUBWOOFER jack
and the subwoofer to the amplifier.
Connecting the speaker cable
1. Strip away 5/8 inch (15 mm) of wire insulation.
2. Twist wire ends very tight.
3. Unscrew
4. Insert wire
5. Screw
Front left
speaker
Front right
speaker
Surround left
speaker
Surround right
speaker
Connecting speakers
Center
speaker
Subwoofer
• Be sure to connect the positive and negative cables for the
speakers properly. If they are mixed up, the left and right signals
will be reversed and the audio will sound unnatural.
• Do not connect more than one speaker cable to one speaker
terminal. Doing so may damage the DTR-7.2.
• Connect your surround back speaker to the SURR BACK
SPEAKER terminals (see this page).
Connecting speakers
Caution:
Connect only speakers with an impedance between 4 and 16 Ω to
the DTR-7.2. If the impedance of even one speaker is between 4
and 6 Ω, be sure to set the speaker impedance setting
accordingly (see page 29).
• To prevent damage to circuitry,
never short-circuit the positive (+)
and negative (–) speaker wire.
NO!
Surround
Back speaker
DIGITAL
OUTPUT
PRE OUT
ANTENNA
DIGITAL
INPUT
OPT
COAX
2
3
1
2
3
FRONT
SUB
SURR
SURR
BACK
CENTER
R
L
AUDIO
R
L
PH
CD
OUT
IN
TAPE
R
L
AUDIO
VIDEO
S VIDEO
MONITOR
OUT
R
L
OUT
IN
OUT
IN
OUT
IN
IN
IN
ZONE 2
DVD
VIDEO 1
VIDEO 2
VIDEO 3
VIDEO 4
AUDIO
AUDIO
VIDEO
S VIDEO
COMPONENT
VIDEO
Y
P
B
P R
OUTPUT
INPUT 1
Y
P
B
P R
INPUT 2
Y
P
B
P R
L
RL
R
AC OUTLETS
AC 120 V 60 Hz
SWITCHED
TOTAL 120W 1A MAX.
I R
IN
OUT
12V
TRIGGER
ZONE 2
REMOTE
CONTROL
1
OPT
GND
AM
4 OHMS MIN. OR
6 OHMS MIN.
/SPEAKER
SEE
INSTRUCTION
MANUAL FOR
CORRECT
SETTINGS.
CAUTION
:
SPEAKER
IMPEDANCE
A
B
A
B
I R OUT 40K
I
R OUT 56K
DC IN
24V 4A
ZONE A
OUT
ZONE B
OUT
ZONE D
OUT
ZONE C
OUT
AV RECEIVER
MODEL NO. DTR-7.2
AC INLET
RS 232
FM
75
DIGITAL
INPUT
SURR BACK
SPEAKER
FRONT SPEAKERS
SURR SPEAKERS
CENTER
SPEAKER
R
L
R
L
MULTI CH
INPUT
FRONT
SUB
SURR
SURR
BACK
CENTER
15mm
1
34 5
2
Notes:
• When you are using only one speaker or when you wish to listen to
monaural (mono) sound, a single speaker should never be
connected in parallel to both the right and left-channel terminals
simultaneously.
R
L
R
L
SPEAKERS
+–
+–
R
L
R
L
SPEAKERS
+–
+–
