4/93 PAGE
Q6064 or TR 2SA1962-R ( 1) 2202832
Q6065 TR 2SA1962-O 1 2202833
Q6065 or TR 2SA1962-R ( 1) 2202832
Q6066 TR 2SA1962-O 1 2202833
Q6066 or TR 2SA1962-R ( 1) 2202832
<Notes>
When replacing the following the transistors, use ones of the same hfe rank as the original type.
Ref. No. : Q6050 - 6060, Q6051 - 6061, Q6052 - 6062, Q6053 - 6063, Q6054 - 6064, Q6055 - 6065, Q6056 - 6066
T901 P TRANS NPT-1571D 1 2301935
!, <DD>
T901 P TRANS NPT-1571M 1 2301936A
!, <MA
U01 AMPLIFIER PC board ass'y NAAMP-9477-1L 1
1B209577-1L
U02 THERMAL SENSOR PC board ass'y NAETC-9478-1L 1
1B209578-1L
U04 TERMINAL PC board ass'y NAETC-9480-1L 1
1B209580-1L
U07 AMPLIFIER PC board ass'y NAASP-9483-1L 1
1B209583-1L
U08 SP TERMINAL PC board ass'y NATRM-9488-1Q 1
1T209588-1Q
<DD>
NATRM-9488-1T 1
1T209588-1T
<MA>
U09 SP TERMINAL PC board ass'y NATRM-9489-1Q 1
1T209589-1Q
<DD>
NATRM-9489-1T 1
1T209589-1T
<MA>
U10 POWER SUPPLY PC board ass'y NAPS-9490-1Q 1
1T209590-1Q
<DD>
NAPS-9490-1T 1
1T209590-1T
<MA>
U11 INLET PC board ass'y NAETC-9491-1Q 1
INCLUDED IN REF.NO.U10
<DD>
NAETC-9491-1T 1
INCLUDED IN REF.NO.U10
<MA>
U13 AMPLIFIER PC board ass'y NACLA-9493-1Q 1
1T209593-1Q
<DD>
NACLA-9493-1T 1
1T209593-1T
<MA>
U14 HOLDER PC board ass'y NAETC-9494-1Q 1
---
NSP
NAETC-9494-1T 1
---
NSP
U15 HOLDER PC board ass'y NAETC-9495-1Q 1
---
NSP
NAETC-9495-1T 1
---
NSP
U16 MICROPROCESSOR AND DAC NADG-9504-1N 1
1B209504-1N
<DD>
PC board ass'y NADG-9504-1P 1
1B209504-1P
<MA>
U17 VIDEO PC board ass'y NAVD-9505-1N 1
1B209505-1N
<DD>
NAVD-9505-1P 1
1B209505-1P
<MA>
U19 XM PC board ass'y NARF-9507-1N 1
1B209507-1N
<DD>
NARF-9507-1P 1
1B209507-1N
<MA>
U20 HDMI PC board ass'y NAHDM-9702-1A 1
1B209502-1A
U21 DISPLAY PC board ass'y NADIS-9096-2A 1
1B209596-2A
U22 DISPLAY PC board ass'y NADIS-9097-2A 1
1B209597-2A
U23 HEADPHONE PC board ass'y NAETC-9098-2A 1
1B209598-2A
U24 POWER SUPPLY PC board ass'y NAPS-9099-2A 1
1B209599-2A
U25 FRONT OPT PC board ass'y NAETC-9100-2A 1
1B209500-2A
U26 VOLUME PC board ass'y NADIS-9101-2A 1
1B209501-2A
U28 HOLDER PC board ass'y NAETC-9103-2A 1
---
NSP
U011 TUNER UNIT ENG06507QFUS 1 240156
<DD>
U011 or TUNER UNIT FAE385-A11US ( 1) 240152
<DD>
U011 TUNER UNIT FAE485-E11EU 1 240154
<MA
