Integra DTR-7.9 Service Manual

5/93 PAGE
DTR-7.9
PC BOARD PARTS LIST
U01
AMPLIFIER PC BOARD(NAAMP-9477-1L)
U02
THERMAL SENSOR PC BOARD(NAETC-9478-1L)
U04
TERMINAL PC BOARD(NAETC-9478-1L)
U07
AMPLIFIER PC BOARD(NAASP-9483-1L)
CIRCUIT NO. PART NAME DESCRIPTION Q'TY PART NO. (SN) REMARKS
Q5501 IC R2A15215FP 1 22242516R3
Q5502 IC M61540FP 1 22242497R2
Q5503 IC NJM4580M-D 1 22241448R2
Q5600 TR RN1441 1 2215410R2
Q5601 TR RN1441 1 2215410R2
Q5602 TR RN1441 1 2215410R2
Q5603 TR RN1441 1 2215410R2
Q5604 TR RN1441 1 2215410R2
Q5605 TR RN1441 1 2215410R2
Q5606 TR RN1441 1 2215410R2
Q5607 TR RN1441 1 2215410R2
Q5610 TR RN1441 1 2215410R2
Q5611 TR RN1441 1 2215410R2
Q5612 TR RN1441 1 2215410R2
Q5613 TR RN1441 1 2215410R2
Q5614 TR RN1441 1 2215410R2
Q5615 TR RN1441 1 2215410R2
Q5616 TR RN1441 1 2215410R2
Q5617 TR RN1441 1 2215410R2
Q5618 IC NJM4580M-D 1 22241448R2
Q5630 IC NJM4580M-D 1 22241448R2
Q5670 IC 78M15HF(NJM78M15FA) 1 222780155JRC
Q5670 or IC UPC78M15AHF-AZ ( 1) 222780155NEC
Q5670A HEAT SINK RAD-196 1 27160545
Q5670B SCREW 3P+10FN(3BC) 1 82143010GR
Q5671 IC 79M15HF(NJM79M15FA) 1 222790155JRC
Q5671 or IC UPC79M15HF-AZ ( 1) 222790155NEC
Q5671 or IC 79M15F(AN79M15F) ( 1) 222790155MAT
Q5671B SCREW 3P+10FN(3BC) 1 82143010GR
Q5684 TR 2SC2235-O(TPE6_F) 1 2211653T
Q5685 TR 2SA965-O(TPE6_F) 1 2211643T
Q5700 TR RN1402 1 2214470R2
Q5701 TR RN1402 1 2214470R2
Q5903 TR RN1441 1 2215410R2
Q5904 TR RN1441 1 2215410R2
