TERMINAL DESCRIPTION(7/10)
IC BLOCK DIAGRAMS AND TERMINAL DESCRIPTIONS -49
Q8200: FLI30336 (Video Processor, TORINO)
TX-SR806/SA806
DSYNC and CLK
I/O
I/O
I/O
I/O
When display drive type is TTL, this is panel output pixel clock.
When display drive type is TTL, this is panel output V-sync.
When display drive type is TTL, this is panel output H-sync.
When display drive type is TTL, this is panel output data enable.
DCLK
DVS
DHS
DEN
P24
R26
P25
P26
Pin name Pin# I/O Description
Display Port Power
P
G
AP
AG
LVDS power(3.3V).
LVDS Ground.
LVDS analog power(3.3V)
LVDS PLL ground.
DCLK
DVS
DHS
DEN
E26,H26,
J26,M26
E25,H25,
J25,M24,
M25
H24
H23
Pin name Pin# I/O Description
Display Port Power
I/O
I/O
I/O
I/O
I/O
I/O
Audio/video synchronizer input word select.
Audio/video synchronizer input clock.
Audio/video synchronizer input data.
Audio/video synchronizer output word select.
Audio/video synchronizer output clock.
Audio/video synchronizer output data.
AVS_IN_WORD_SEL
AVS_IN_SCL
AVS_IN_DATA
AVS_OUT_WORD_SEL
AVS_OUT_SCL
AVS_OUT_DATA
AD12
AF14
AC12
AE14
AE13
AD14
Pin name Pin# I/O Description
Dedicated GPIO
I/O
I/O
I/O
I/O
I/O
I/O
General purpose I/O 42.
General purpose I/O 43.
General purpose I/O 44.
General purpose I/O 45.
General purpose I/O 46.
General purpose I/O 47.
GPIO_42
GPIO_43
GPIO_44
GPIO_45
GPIO_46
GPIO_47
T24
T25
T26
R23
R24
R25
Pin name Pin# I/O Description
External OSD
I/O
I/O
I/O
External OSD clock.
External OSD HSync.
External OSD VSync.
EXT_OSD_CLK
EXT_OSD_HS
EXT_OSD_VS
AF13
AC13
AD13
Pin name Pin# I/O Description
