143
Zone 2 and Zone 3—Continued
If you’ve connected your Zone 2 or Zone 3 speakers to
an amp with no volume control, set the “Zone2 Out” or
“Zone3 Out” setting, respectively, to “Variable” so that
you can set the zone’s volume, balance, and tone on the
AV r ec eiv e r .
Note:
This procedure can also be performed on the AV receiver
by using its [Setup] button, arrow buttons, and [Enter]
button.
This section explains how to use Zone 2 and Zone 3.
Zone 2/Zone 3 Out Settings
1
Press the [Receiver] Remote
Mode button, followed by the
[Setup] button.
The main menu appears onscreen.
If the main menu doesn’t appear, make
sure the appropriate external input is
selected on your TV.
2
Use the Up and Down [q]/[w] but-
tons to select “7. Hardware
Setup”, and then press [Enter].
The “Hardware Setup” menu appears.
3
Use the Up and Down [q]/[w] but-
tons to select “2. Zone2/Zone3”,
and then press [Enter].
The “Zone2/Zone3” screen appears.
4
Use the Up and Down [q]/[w] but-
tons to select “Zone2 Out” or
“Zone3 Out”, and use the Left
and Right [e]/[r] buttons to
select:
Fixed:
The Zone 2 or Zone 3 volume must
be set on the amp in that zone.
Variable:
The Zone 2 or Zone 3 volume can
be set on the AV receiver.
Receiver
S
e
t
u
p
Enter
Enter
Enter
Enter
7-2. Zone2/Zone3
Powered Zone2
Zone2 Out
Zone3 Out
Not Act
Fixed
Fixed
MOVE VALUE RETURN
RETURN
EXIT
SETUP
Enter
Enter
5
Press the [Setup] button.
Setup closes.
Using Zone 2 and Zone 3
S
e
t
u
p
Zone 2
Zone 3
Tone
Off Level ,
+
-
On Standby
TV
Input
TV CH
TV VOL
--
/
---
10 11 12
D.TUN
+10
0
Clear
123
456
789
Input Selector
VCR
/
DVR CBL
/
SAT
DVD
Tape
Tuner
CD
Phono Net/USB
Game
/
TV
Macro
123
VCRDVD
CDR/MD/Dock
CD
Zone
2
Remote Mode
Dimmer
Tape/AMP
Sleep
Receiver
TV
Net/USB
Cable
VOL
CH
Disc
Album
+
-
Enter
T
o
p
M
e
n
u
M
e
n
u
Display Muting
E
x
i
t
G
u
i
d
e
Prev
CH
R
e
t
u
r
n
S
e
t
u
p
RC-688M
Audio
Repeat
Play Mode
Open/Close
Listening Mode
DVD HDD
Playlist
RandomRec
Test Tone
CH Sel
Direct
Stereo
Level
+
Level
-
L Night
Audio Sel
THX All ST
Re-EQ
Subtitle
Video Off
VCR
Surround
SAT
Zone
3
AUX 1 AUX 2
Zone3
Zone2
Muting
On
Standby
Level–,
Level+
Input
Selector
To Next Page
