Integra DTR-9.9 - Connecting a Cassette, CDR, Minidisc, or DAT Recorder

43
Connecting the AV Receiver—Continued
• With connection , you can play and record or listen in Zone 2 or Zone 3.
• To connect the recorder digitally for playback, use connections and , or and .
• To connect the recorder digitally for recording, use connection .
Connecting a Cassette, CDR, MiniDisc, or DAT Recorder
Connection AV receiver Signal flow Cassette, CDR, MD, or DAT recorder
TAPE IN L/R
TAPE OUT L/R
⇐
⇒
Analog audio L/R output
Analog audio L/R input
DIGITAL COAXIAL IN 2 (VCR/DVR)
⇐
Digital coaxial output
DIGITAL OPTICAL IN 2 (CD)
⇐
Digital optical output
DIGITAL OPTICAL OUT
⇒
Digital optical input
COAXIAL
IN 2
(VCR/DVR)
COAXIAL
OUT
AUDIO
IN
LR
OPTICAL
OUT
OPTICAL
IN 2
(CD)
OPTICAL
IN
L
R
IN
TAPE
AUDIO
OUT
LR
L
R
TAPE
OPTICAL
b
c
a
a
d
Step 1:
Choose a connection that matches your recorder ( , , , or ), and then make the connection.
a b c d
Cassette, CDR, MD, etc.
Connect one or the other
Connection must be
assigned (see page 55)
a
a b a c
d
a
b
c
d
