23
Speaker Placement
—Continued
Main room A: 7.1 ch speaker system and the two additional front speakers connected through the bi-
amp connection (when you want to use either the 7.1 ch speakers or the additional front speakers
according to the source)
• Set all the zone parameters for speaker system [A] to “Main A.”
• For speaker system [B], set the front speaker parameters to “Main A” and the surround back speaker parameters to
“Bi-Amp for Front” (For details on connections, see page 27).
• When you want to use the front speakers of speaker system [B] for specific sources, select the source and set the
front speaker parameters to “B” in the listening mode setup menu.
*When using the bi-amp connections, the two speaker systems cannot be used to output simultaneously.
Main room A: 5.1 ch speaker system including the front speakers connected through the bi-amp
connections
• For speaker system [A], set the surround back speaker parameters to “Bi-Amp for Front” and all the other speaker
parameters to “Main A” (For details on speaker connections, see page 27).
• For speaker system [B], set the speaker parameters to “Not Used.”
*When using the bi-amp connections, you cannot use Zone 2 since the surround back channel is used for the front speakers of main
room A.
FL
FL
C
SBL SBR
SW
FR
FR
SR
SL
Here is an example of the
stereo listening mode.
1-1.Speaker Config
=====================
Speaker A
a.Front L/R :Main A
b.Center :Main A
c.Surr L/R :Main A
d.Surr Back
:Main A 2ch
e.Subwoofer :Main A
Speaker B
f.Front L/R :Main A
g.Center :Not Used
h.Surr L/R :Not Used
i.Surr Back
:Bi-Amp for Front
j.Subwoofer :Not Used
To Next Page
