21555 Non-Transparent PCI-to-PCI Bridge User Manual 123
List of Registers
2F:2E
6F:6E
Subsystem ID Register, page
154
0000 Y Secondary Y
33:30 (P)
73:70 (S)
Primary Expansion ROM BAR,
page 175
00000000 Via Setup Via Setup Y
34
74
Enhanced Capabilities Pointer
Register, page 154
DC — NY
37:35 (P)
77:75 (S)
Reserved 000000 — NY
3B:38 (P)
7B:78 (S)
Reserved 00000000 — NY
3C (P)
7C (S)
Primary and Secondary Interrupt
Line Registers, page 154
00 — YY
3D (P)
7D (S)
Primary and Secondary Interrupt
Pin Registers, page 155
01 — NY
3E (P)
7E (S)
Primary and Secondary Minimum
Grant Registers, page 155
00 Y Secondary Y
3F (P)
7F (S)
Primary and Secondary
Maximum Latency Registers,
page 155
00 Y Secondary Y
45:44 (P)
05:04 (S)
Primary and Secondary
Command Registers, page 149
0000
47:46 (P)
07:06 (S)
Primary and Secondary Status
Registers, page 150
0290 — YY
4B:49 (P)
0B:09 (S)
Primary and Secondary Class
Code Registers, page 152
068000 Y N Y
4C (P)
0C (S)
Primary and Secondary Cache
Line Size Registers, page 152
00 — YY
4D (P)
0D (S)
Primary Latency and Secondary
Master Latency Timer Registers,
page 153
00 — YY
53:50 (p)
13:10 (s)
Secondary CSR Memory BAR 00000000 — YY
57:54 (p)
17:14 (s)
Secondary CSR I/O BAR 00000001 — YY
5B:58 (P)
1B:18 (S)
Upstream I/O or Memory 0 BAR 00000000 Via Setup Via Setup Y
5F:5C (P)
1F:1C (S)
Upstream Memory 1 BAR 00000000 Via Setup Via Setup Y
63:60 (P)
23:20 (S)
Upstream Memory 2 BAR 00000000
Via Chip
Control 1
Via Chip
Control 1
Y
67:64 (P)
27:24 (S)
Reserved 00000000 — NY
73:70 (P)
33:30 (S)
Reserved 00000000 — NY
7C(P)
3C (S)
Primary and Secondary Interrupt
Line Registers, page 154
00 — YY
Table 32. Configuration Space Address Register (Sheet 2 of 5)
Byte
Offset
(Hex)
Register Name
Reset Value
(Hex)
Preload
Write
Access
Read
Access
