21555 Non-Transparent PCI-to-PCI Bridge User Manual 179
List of Registers
16.10 SROM Registers
This sections describes the SROM registers. See Chapter 9 for theory of operation information.
2
Read/Write
Control
R/W
PROM read/write control bit. This bit may be written with the same
CSR access that sets the PROM Start bit.
When 0, the 21555 performs a read of the PROM when the
PROM Start bit is set to a 1.
When 1, the 21555 performs a write of the PROM when the
PROM Start bit is set to a 1.
Reset value is 0
3SROM_POLL R
This bit reflects the status of the serial ROM as a result of a polling
operation following a write all, erase all, write, or erase operation.
This bit is set automatically by the 21555 when one of these
operations is initiated, and cleared when a subsequent poll of the
serial ROM indicates that the operation is complete.
Reset value is 0
7:4 Reserved R Reserved. Reads only as 0.
Table 113. Mode Setting Configuration Register (Sheet 1 of 2)
This register reflects the various mode settings selected by strapping the pr_ad pins, as well as whether the
64-bit extension is enabled.
Primary byte offset: D6h
Secondary byte offset: D6h
Bit Name R/W Description
0
Serial
Preload
Enabled
R
Indicates whether a serial preload was performed.
When 0, the serial preload enable sequence was not detected and the
register preload was not performed.
When 1, the serial preload enable sequence was detected and the
register preload was performed.
1
Primary
Lockout
Reset Value
R
Indicates the primary lockout reset value determined by sampling pr_ad[3]
during reset.
When 0, signal pr_ad[3] was sampled low, causing the this bit to be low
upon completion of chip reset.
When 1, signal pr_ad[3] was sampled high, causing the this bit to be set
high upon completion of chip reset.
2
Synchronous
Enable
R
Indicates whether synchronous or asynchronous mode was selected by
sampling pr_ad[4] during reset.
When 0, signal pr_ad[4] was sampled low, selecting synchronous mode.
When 1, signal pr_ad[4] was sampled high, selecting asynchronous
mode.
Table 112. ROM Control Register (Sheet 2 of 2)
Byte Offsets: 0CFh
Bit Name R/W Description
