174 21555 Non-Transparent PCI-to-PCI Bridge User Manual
List of Registers
16.8 Scratchpad Registers
See Chapter 11 for theory of operation information.
Table 104. Primary Clear IRQ Mask and Secondary Clear IRQ Mask Registers
Bit Name R/W Description
15:0 CLR_IRQM R/W1TC
• When 0, an interrupt is generated on the 21555’s primary or
secondary interface when the corresponding Primary or
Secondary Interrupt Request bit is a 1.
• When 1, the corresponding interrupt request bit cannot generate
an interrupt.
Writing a 1 to a bit in this register clears the IRQ Mask bit to 0.
Writing a 0 to any bit in this register has no effect. Reading this
register returns the current status of the IRQ Mask bits.
• Reset value is FFFFFFFFh
Table 105. Primary Set IRQ Mask and Secondary Set IRQ Mask Registers
Bit Name R/W Description
15:0 SET_IRQM R/W1TS
• When 0, an interrupt is generated on the 21555’s primary or
secondary interface when the corresponding Primary or
Secondary Interrupt Request bit is a 1.
• When 1, the corresponding interrupt request bit cannot
generate an interrupt.
Writing a 1 to a bit in this register sets the IRQ Mask bit to 1.
Writing a 0 to any bit in this register has no effect. Reading this
register returns the current status of the IRQ Mask bits.
• Reset value is FFFFFFFFh
Table 106. Scratchpad 0 Through Scratchpad 7 Registers (Sheet 1 of 2)
Bit Name R/W Byte Offset: Description
31:0 SCRATCH0 R/W 0AB:0A8h 32-bit scratchpad register 0.
31:0 SCRATCH1 R/W 0AF:0ACh 32-bit scratchpad register 1.
31:0 SCRATCH2 R/W 0B3:0B0h 32-bit scratchpad register 2.
These registers affect primary and secondary interrupts in the same way and are described
Primary Clear IRQ Mask Secondary Clear IRQ Mask
Byte Offset: 0A1:0A0h 0A3:0A2h
These registers affect primary and secondary interrupts in the same way and are described together.
Offsets Primary Set IRQ Mask Secondary Set IRQ Mask
Byte 0A5:0A4h 0A7:0A6h
