130 21555 Non-Transparent PCI-to-PCI Bridge User Manual
List of Registers
16.4 Address Decoding
16.4.1 Primary and Secondary Address
This section covers pages 16-130 through 16-140 and includes tables Table 34 through Table 60. See Chapter 4
for theory of operation information.
0FF:0D0 Reserved 00000000 N Y
1FF:100
Upstream Memory 2 Lookup Table, page
147
Upstream Memory 2 Look-up Table
Indeterminate Y Y
FFF:200 Reserved 00000000 N Y
Table 34. Primary CSR and Downstream Memory 0 Bar
a
(Sheet 1 of 2)
• Primary byte offset: 13:10h
• Secondary byte offset: 53:50h
The Primary CSR and Downstream Memory 0 BARs map the 21555 registers into primary memory space.
They can specify a downstream memory range for forwarding of memory transactions.
To specify a downstream forwarding range, load the Downstream Memory 0 Setup Register from the optional
SROM or the local processor This load must occur before configuration software running on the host
processor can access this register.
Local processor access of the setup register should be done before the Primary Lockout Reset Value bit is
cleared.
Bit Name R/W Description
0
Space
Indicator
R
Indicates the type of address space to setup.
When 0, it indicates that memory space is requested.
2:1 Type R
Indicates size and location of this address space.
Reset value is To 00 indicating that this space can be mapped anywhere in
32-bit memory.
Table 33. CSR Address Map (Sheet 5 of 5)
Byte
Offset
(Hex)
Register Name Reset Value Write Access Read Access
To Next Page
